Ningbo Xin Chang Machinery Co.,Ltd
ブランド: 新昌市
についてのサポート: 200 Sets /Month
| Model Item |
AC-05 | ||||
| Cooling Capacity | kcal/h | 13046 | |||
| KW | 15.17 | ||||
| Input power | KW | 5.23 | |||
| Power Supply | 3PH~440V/50HZ | ||||
| Refrigerant | Model | R22 | |||
| Control type | Expansion valve | ||||
| Compressor | Type | Hermetic scroll type | |||
| Power | kw | 4.1 | |||
| Condenser | Type | High effective copper pipes lovered into aluminllm fins+low noise rotor fan | |||
| Power | kw | 0.38 | |||
| Cooling air Flow | m3/h | 5000 | |||
| Evaporator | Type | Water tank with coil | |||
| Refrigerated Water Flow | m3/h | 2.62 | |||
| Water Tank Capacity(L) | 60 | ||||
| Inlet and Outlet pipe caliber | 1″ | ||||
| Water Pump | Power (KW) | 0.75 | |||
| Lift(M) | 20 | ||||
| Safety Protection | Compressor superheating protection, Overcurrent protection, High and low pressure protection, Over temperature protection, Phase sequence/ Phase-lacking protection, Exhaust over heating protection | ||||
| Weight of the Machine | KG | 175 | |||
| MEAS. | MM | 1140*560*1040 | |||
